KNYEE ENERGY - KNY12100 / KNY12200

Brand: KNYEE ENERGY
Model: KNY12100 / KNY12200

The KNYEE ENERGY Portable Storage Battery is a versatile and reliable energy storage solution designed for residential, recreational, and commercial use. With capacities of 1280Wh (12.8V, 100Ah) and 2560Wh (12.8V, 200Ah), this portable lithium iron phosphate (LiFePO4) battery offers exceptional safety, longevity, and compatibility with mainstream inverters. Its compact design, advanced BMS management, and corrosion-resistant materials make it ideal for home use, RVs, marine applications, outdoor camping, and more.

---

* Minimum Order Quantity (MOQ) of 20 units *

Key Features

Advanced Energy Storage Technology

• High-Quality LiFePO4 Cells: Ensures superior safety, long cycle life (3000 cycles at 80% Depth of Discharge), and environmental sustainability.
• High Energy Density: Delivers 1.28kWh or 2.56kWh of energy in a compact and lightweight design, making it portable and space-efficient.
• Scalable Compatibility: Compatible with mainstream inverters, ensuring seamless integration into existing solar systems.

Safe and Reliable Performance

• Built-in Fire Safety: Equipped with advanced safeguards such as overcharge, over-discharge, short circuit, and thermal protection.
• Wide Operating Temperature Range: Operates efficiently in temperatures ranging from -20°C to 60°C (discharge) and 0°C to 55°C (charge).
• Protection Rating: IP20 ensures resistance to dust and water ingress, making it suitable for indoor and outdoor use.

User-Friendly Design

• Portable Handle: Designed for easy movement, making it convenient for outdoor and recreational use.
• LED Display: Provides real-time information on State of Charge (SOC) and battery status, ensuring easy monitoring.
• Quick Installation: Features plug-and-play terminals (+/-) and supports parallel connections for scalable energy storage solutions.

Additional Features

• Corrosion-Resistant Materials: Durable shell made of high-quality plastic ensures long-term reliability.
• Advanced BMS Management: Monitors and optimizes battery performance in real-time, extends service life, and enables remote control via mobile app.
• Self-Discharge Rate: Less than 2% per month, ensuring the battery retains its charge during periods of inactivity.

---

Product Specifications

KNY12100 (1.28kWh)

• Nominal Voltage: 12.8Vdc
• Voltage Range: 11V–14.6V
• Nominal Capacity: 100Ah
• Rated Capacity: 1.28kWh
• Cycle Life: 3000 cycles @ 80% DOD
• Dimensions: 295mm x 203mm x 230mm
• Weight: 10kg
• Shell Material: Plastic
• Protection Rating: IP20

KNY12200 (2.56kWh)

• Nominal Voltage: 12.8Vdc
• Voltage Range: 11V–14.6V
• Nominal Capacity: 200Ah
• Rated Capacity: 2.56kWh
• Cycle Life: 3000 cycles @ 80% DOD
• Dimensions: 522mm x 245mm x 225mm
• Weight: 20kg
• Shell Material: Plastic
• Protection Rating: IP20

Charging Parameters

• Recommended Charging Current: 50A (KNY12100) / 100A (KNY12200)
• Max. Charging Current: 100A (KNY12100) / 200A (KNY12200)
• Recommended Charging Voltage: 12.8V
• Max. Charging Voltage: 14.6V

Discharging Parameters

• Recommended Discharging Current: 50A (KNY12100) / 100A (KNY12200)
• Max. Discharging Current: 100A (KNY12100) / 200A (KNY12200)

Environmental Specifications

• Operating Temperature Range:
• Charge: 0°C to 55°C
• Discharge: -20°C to 60°C
• Storage Temperature Range: -20°C to 45°C
• Humidity: 5%–95% (non-condensing)

Certifications

Safety Certification: CE
Transportation Safety Certification: UN38.3, Class 9

---

Applications

• Residential Use: Ideal for home energy storage systems, providing reliable backup power and reducing reliance on the grid.
• Recreational Use: Suitable for RVs, boats, and marine applications, ensuring uninterrupted power during travel.
• Outdoor Camping: Perfect for outdoor enthusiasts, offering portable and reliable energy for camping trips.
• Emergency Backup Power: Ensures uninterrupted power supply during grid outages, supporting critical appliances and devices.

---

Benefits

• High Efficiency: Advanced LiFePO4 cells ensure maximum energy storage and minimal losses.
• Durability: With a lifecycle of **3000 cycles at 80% DOD**, this battery offers long-term reliability and reduced maintenance costs.
• Safety: Corrosion-resistant materials, advanced BMS management, and temperature-controlled heat dissipation ensure safe operation.
• Portability: Lightweight design and integrated handles make it easy to carry and transport.
• Versatility: Compatible with mainstream inverters and suitable for various applications, including residential, recreational, and commercial use.

---

Why Choose the KNYEE ENERGY Portable Storage Battery?

• Combines LiFePO4 cells, portable design, and advanced BMS control for superior performance and durability.
• Backed by rigorous testing and certifications such as CE, UN38.3, and Class 9, ensuring safety, reliability, and compliance with global standards.
• Suitable for residential, recreational, and commercial applications, providing flexibility and value.
• Compact and lightweight design makes it easy to install and transport.

---

Upgrade Your Energy Storage System

Invest in the KNYEE ENERGY Portable Storage Battery for a reliable, efficient, and eco-friendly energy storage solution.

Order now and experience the next generation of portable energy storage technology with KNYEE ENERGY.

---

From SOLAR.ID of Jakarta, Indonesia

KNYEE ENERGY -  KNY12100 / KNY12200 Data Sheet
