Lithium Valley Technology - LVAF-ASL
Contact for Price. Pricing varies based on the number of units and current market rates. For a personalized quote tailored to your project, please reach out to us!
Couldn't load pickup availability
Brand: Lithium Valley Technology
Model: LVAF-ASL
The Lithium Valley Technology LV-BAT-R5.12Aa is a high-performance 3U rack-mount lithium iron phosphate (LiFePO4) battery, specifically designed for residential and commercial energy storage. With a capacity of 5.12kWh (51.2V, 100Ah), this battery offers a reliable, efficient, and scalable solution for solar energy storage, backup power, and off-grid systems. Its advanced safety features, long lifecycle, and compatibility with various inverters make it an ideal choice for modern households and businesses seeking energy independence.
---
Key Features
Advanced Energy Storage Technology
- High-Quality LiFePO4 Cells: Ensures superior safety, long cycle life (6000 cycles at 80% Depth of Discharge), and environmental sustainability.
- High Energy Density: Delivers 5.12kWh of energy in a compact design (550mm x 440mm x 130mm), making it space-efficient and versatile.
- Scalable Capacity: Supports up to 15 units in parallel, enabling flexible energy storage solutions tailored to your specific needs.
Safe and Reliable Performance
- Built-in Fire Safety: Equipped with advanced safeguards such as overcharge, over-discharge, short circuit, and thermal protection.
- Wide Operating Temperature Range: Operates efficiently in temperatures ranging from -20°C to 60°C (discharge) and 0°C to 55°C (charge).
- Protection Rating: IP20 ensures resistance to dust and water ingress, making it suitable for indoor installations.
User-Friendly Design
LED Display: Provides real-time information on State of Charge (SOC) and battery status, ensuring easy monitoring.
- Quick Installation: Features plug-and-play terminals (+/-) and RS485 parallel connection for seamless integration into existing solar systems.
- Natural Cooling: Designed for efficient heat dissipation without the need for additional cooling systems.
---
Product Specifications
- Model Number: LV-BAT-R5.12Aa
- Nominal Voltage: 51.2V
- Rated Capacity: 100Ah
- Energy Storage: 5.12kWh
- Dimensions: 550mm x 440mm x 130mm
- Weight: 44.35kg – 47.85kg
- Charging Cut-off Voltage: 56.16V
- Discharge Cut-off Voltage: 45.6V
- Recommended Charge/Discharge Current: 50A
- Maximum Continuous Charge/Discharge Current: 100A
- Instantaneous Discharge Current: 200A (1 second)
- Cycle Life: 6000 cycles @ 80% DOD
- Operating Temperature Range:
- Charge: 0°C to 55°C
- Discharge: -20°C to 60°C
- Storage Environment:
- Short-term (up to 3 months): 20°C – 45°C (50% SOC)
- Long-term (over 3 months): 25°C ± 3°C, Humidity: 65% ± 20% RH
- Cooling Method: Natural convection
- Protection Rating: IP20
- Certifications: CB, IEC62619, UL1973, UL9540A, UKCA, CE-EMC, CE-GPSD, EN62619, UN38.3, MSDS
---
Applications
- Residential Use: Ideal for home solar energy storage systems, providing reliable backup power and reducing reliance on the grid.
- Commercial Use: Suitable for businesses, offices, and industrial facilities requiring scalable energy storage solutions.
- Off-Grid Installations: Perfect for remote locations where access to the grid is limited or unavailable.
- Emergency Backup Power: Ensures uninterrupted power supply during grid outages, supporting critical appliances and devices.
---
Benefits
- High Efficiency: Advanced LiFePO4 cells ensure maximum energy storage and minimal losses.
- Scalability: Allows for flexible capacity expansion to meet growing energy demands.
- Durability: With a lifecycle of **6000 cycles at 80% DOD**, this battery offers long-term reliability and reduced maintenance costs.
- Safety: Vertical cell assembly, temperature-controlled heat dissipation, and high-temperature resistance ensure safe operation.
- Easy Integration: Quick plug-and-play design simplifies installation and reduces setup time.
---
Why Choose the Lithium Valley Technology LV-BAT-R5.12Aa?
- Combines LiFePO4 cells, natural cooling, and advanced BMS control for superior performance and durability.
- Backed by rigorous testing and certifications such as CB, IEC62619, UL1973, UL9540A, UKCA, CE-EMC, CE-GPSD, EN62619, UN38.3, and MSDS, ensuring safety, reliability, and compliance with global standards.
- Suitable for residential, commercial, off-grid, and specialized applications, providing flexibility and value.
- Compact and lightweight 3U design makes it easy to install in homes, offices, or commercial spaces.
---
Upgrade Your Energy Storage System
Invest in the Lithium Valley Technology LV-BAT-R5.12Aa for a reliable, efficient, and eco-friendly energy storage solution.
Order now and experience the next generation of solar and storage technology with Lithium Valley Technology.
---
